Out of stock
DG122S-1/4-E
1/4" COLLET DIE GRINDER
22,000 RPM Free Speed
Features
- Steel body construction for maximum durability
- Extended length for additional application access
- Lever throttle standard
- Side air exhaust
Specifications
| Rated hp | 0.9 |
|---|---|
| Rated kW | 0.67 |
| Free Speed rpm | 25000 |
| Throttle Type | Lever |
| Spindle Output in | 1/4" Collet |
| Wheel Type & Thickness | Mounted Burr |
| Overall Length - in | 1113/100 |
| Overall Length mm | 283 |
| Air Inlet NPT in | 1/4 |
| Weight - lb | 3 |
| Weight kg | 1.50 |
| Hose ID in | 3/8 |
| Hose ID mm | 10 |
| Exhaust Direction | Side |
| Performance Pressure PSIG | 90 |
| Performance Pressure Bar | 6.2 |
| Air Consumption cfm | 32 |
| Air Consumption l/min | 906 |
| Xrefs | ATP9913LS;DG122S-1-4-E |
