In stock
ATP7522PT-TH
3/4" SQUARE DRIVE PISTOL GRIP IMPACT WRENCH
Features
- Twin hammer mechanism
- Steel hammer casing
- Combo reverse and power regulators
- Composite motor housing
Specifications
| Drive Type | Square |
|---|---|
| Working Torque ft-lb | 1040 |
| Working Torque Nm | 1410 |
| Max Torque ft-lb | 1140 |
| Max Torque Nm | 1546 |
| Tool Duty Rating | Moderate |
| Handle Type | Pistol |
| Throttle Type | Trigger |
| Drive Size - in | 3/4 |
| Impact Mechanism / Clutch Type | Twin Hammer |
| Socket Retainer | Through Hole |
| Housing Construction | Composite Motor Housing, Steel Hammer Case |
| Length - in | 9.3 |
| Length mm | 235 |
| Weight - lb | 8.1 |
| Weight kg | 3.7 |
| Air Inlet NPT in | 3/8 |
| Min Hose ID in | 3/8 |
| Performance Pressure PSIG | 90 |
| Performance Pressure Bar | 6.2 |
