In stock
ATP7520PT-1H
1" SQUARE DRIVE PISTOL GRIP IMPACT WRENCH
Features
- High output twin hammer mechanism
- Bronze end plates for increased motor durability
- Steel hammer case
- Integral muffler for noise reduction
- Three piece housing for ease of repair
Specifications
| Working Torque ft-lb | 800 |
|---|---|
| Working Torque Nm | 1085 |
| Max Torque ft-lb | 1100 |
| Max Torque Nm | 1491 |
| Tool Duty Rating | Super Duty |
| Handle Type | Pistol |
| Throttle Type | Trigger |
| Drive Size - in | 1 |
| Impact Mechanism / Clutch Type | Twin Hammer |
| Socket Retainer | Through Hole |
| Housing Construction | 3 Piece |
| Length - in | 12.50 |
| Length mm | 317 |
| Weight - lb | 12 |
| Weight kg | 5.40 |
| Air Inlet NPT in | 3/8 |
| Min Hose ID in | 1/2 |
| Min Hose ID mm | 13 |
| Performance Pressure PSIG | 90 |
| Performance Pressure Bar | 6.2 |
| Air Consumption cfm | 36 |
| Air Consumption l/min | 1,019 |
| OEM | Ingersoll Rand |
| Comparable OEM Model | IR2920P3 |
