Out of stock
ATP2122-725-2
LARGE DRILL
2 Morse Taper, Roll Throttle, Breast Plate, 725 RPM Free Speed
Features
- Roll throttle for excellent speed control
- Governor controlled motor maintains speed and power under load
- Internal oil reservoir for reduced downtime
- External grease fitting for ease of lubrication
- Self closing throttle with independent reverse
- Ball bearing support for long life and smooth operation
Specifications
| Free Speed rpm | 725 |
|---|---|
| Drilling Capacity Steel in | 9/16 |
| Drilling Capacity Steel mm | 14 |
| Reaming Capacity Steel in | 7/16 |
| Reaming Capacity Steel mm | 11 |
| Reversible | Yes |
| Spindle Attachment in | 2 Morse Taper |
| Net Weight lb | 14.4 |
| Net Weight kg | 6.50 |
| Maximum hp | 1.75 |
| Maximum Kw | 1.31 |
| Side to Center Distance in | 1.44 |
| Side to Center Distance mm | 36.0 |
| Height Over Spindle in | 17.25 |
| Height Over Spindle mm | 438 |
| Air Inlet NPT in | 1/2 |
| Hose ID in | 3/4 |
| Performance Pressure PSIG | 90 |
| Performance Pressure Bar | 6.2 |
| Air Consumption cfm | 50 |
| Air Consumption l/min | 1,416 |
| OEM | Ingersoll Rand |
| Comparable OEM Model | 22 series |
