Out of stock
ATP1580LT-TH
LEVER THROTTLE 1-1/2" DRIVE IMPACT WRENCH
Features
- Precision ball and cam mechanism
- Built-in lubricator
- Vertical and horizontal hangers
- Closed grip handle
- Operator assist Handle
Specifications
| Working Torque ft-lb | 5900 |
|---|---|
| Working Torque Nm | 8000 |
| Max Torque ft-lb | 13560 |
| Max Torque Nm | 18383 |
| Tool Duty Rating | Super Duty |
| Handle Type | T-Handle |
| Throttle Type | Lever |
| Drive Size - in | 3/2 |
| Impact Mechanism / Clutch Type | Ball and Cam |
| Socket Retainer | Through Hole |
| Housing Construction | 3 Piece |
| Length - in | 23.00 |
| Length mm | 584 |
| Weight - lb | 88 |
| Weight kg | 39.90 |
| Air Inlet NPT in | 3/4 |
| Min Hose ID in | 1 |
| Min Hose ID mm | 25 |
| Performance Pressure PSIG | 90 |
| Performance Pressure Bar | 6.2 |
| Air Consumption cfm | 138 |
| Air Consumption l/min | 3,908 |
| OEM | Ingersoll Rand |
| Comparable OEM Model | IR5980A1 |
